| PARTS NAME |
FUNCTION & SPECIFICATION |
QTY |
| MS PIPE |
70X 70 X 4, FOR FRAME STRUCTURE, SQUARE PIPE |
|
| SPRAY GUN |
AUTOMATIC TYPE, GERMAN BASED |
2 |
| SPRAY GUN |
MANUAL TYPE |
2 |
| SPRAY MOTOR |
MOTOR CG / ROTOMOTIVE, 0.5HP WITH GEAR BOX, AUTOMATIC SLIDING ON HARDCHROME SHAFT WITH BEARING BLOCK |
1 |
| SLIDING HARDCHROME SHAFT, WITH BEARING BLOCK |
FOR SMOOTH OPERATION |
2 |
| MAIN CONVEYOR MOTOR |
INDUCTION MOTOR 1 HP, WITH GEAR BOX |
2 |
| BLOWER |
1HP AND 2 HP |
2 |
| SPRAY UNIT TANK |
1 TANK FOR TRAY SPRAY BOOTH, 1 TANK FOR UV VARISH |
2 |
| SPRAY UNIT CONTROL |
GERMAN BASED CONTROLLER |
|
| SPRAY ROLLER |
HARDCHROME SHAFT WITH SS/CHROME PLATING |
|
| UV/IR CONVEYOR CONTROL |
PUSH BUTTON TYPE SCHNEIDER |
|
| IR LAMP |
600MM CURING , MADE IN UK/ USA, IR LAMP USE FOR LEVELLING THIS UV VARNISH AND WE GET FINE RESULTS |
1 |
| HEATER |
600MM LENGTH, MADE IN INDIA, WITH TEMPERATURE CONTROLLER PID |
1 |
| UV LAMP |
CURING 600MM , M1ADE IN UK/USA , WITH 75% AND 100% OPERATION, UV LAMP LIFE 1200-1500 HOURS |
1 |
| UV TRANSFORMER |
100% CU WINDING |
1 |
| ELECTRICAL PANEL |
SCHNEIDER BRAND MCB, CONTACTOR ETC. |
|
