| The latest Vi Series lasers – for 30W and 40W.
Ultra Compact next generation Co2 laser tube cut a wide variety of material
with incredible accuracy. No consumable parts and long operating lifetime
performance, Synrad is the only CO2 laser manufacturer that can boast of
proven operating lifetimes in excess of 45,000 hours (at which time, a simple
and inexpensive gas rell returns the laser to full operation). The New Vi Series
includes a new Temperature Broadcast feature for real-time condition
monitoring and the design efficiently manages thermal resistance and power
to deliver a stable accurate beam. The Vi Series are some of the most compact
and lightest 30 W and 40 W CO₂ lasers. |
| The latest restar Ti-series – for 60W, 80W and 100W.
Maximum power and performance from an air-cooled CO₂ laser is the
drive behind their restar Ti series technology, Synrad’s restar Ti series
lasers are built on technology using a patented hybrid, unstable
resonator design. |
| Auto Focus
The auto focus tools helps to adjust and x focal length by automatic table
up and down. It saves the time of setting the right distance (focal length)
between head and top surface of the materials when you work with more
materials having different thickness. Right focal length is the most
important to get good quality engraving. |
X, Y, Rails
- The linear guideway body consists of an anodized aluminum housing
with a chrome steel gcr15 shaft which is of low friction, noise and
vibration. The pulleys/pinion is equipped with maintenance free U
shape bearings.
- It redene the classic belt drive, putting belts to work in an entirely new
way that reduces the positioning errors and speed limitations of
conventional belt drives.
- Mehta’s linear modules provides high load capacities, high speed,
accuracy and repeatability. The linear bearing system is corrosion
resistant, even after scratching.
|
| Controller
ERICA’s lastest laser engraving & cutting control system has better
stable hardware with antistatic, resistance to high pressure. Based on
5-inch colorful screen, human-machine operation system, with better
operation interface and stronger functions, excellent motion control
functions, high-capacity le memory, with strong compatible 2-way
independent adjustable laser power control interface, strong
compatible U disk drive program, multiple ways general/dedicated IO
control. |
| User Friendly Driver Interface
Virtual Printer Mode, File Send Direct From CorelDRAW |
